商品の詳細:
起源の場所: 中国
ブランド名: Jiayao
証明: ISO 9001:2008
モデル番号: 伸縮式タワー
お支払配送条件:
最小注文数量: 1トン
価格: >=1 Tons,US$25000;>=5 Tons,US$24500
パッケージの詳細: 20GPか40HQ
受渡し時間: 15日
支払条件: LC、T/T
供給の能力: 月産100トン
連絡先 今雑談しなさい

Versatile Telescopic Tower with Height Range from 15 to 30 Meters Suitable for Aerial Work and Industrial Installations

説明
標準: GB / ANSI / TIA-222-G、EN 1991-1-4 および EN 1993-3-1 溶接の標準: AWSD1.1
重さ: -20℃～60℃ 風速: 40m/s
耐風性: 最大120 km/h 材料: ソリッドロッド;スチールチューブ
身長: 30メートルまで 証明: ISO9001:2008 COC
保存 剤 の 治療: 熱浸し 塗装 基本タイプ: 固定ベースまたはモバイルベースのオプション
安全機能: 自動ロック機構、安全ピン 導入時間: 5分未満
製品名: 緊急伸縮通信塔 アプリケーション: 監視、照明、通信
伸縮機構: 油圧システム 亜鉛めっき規格: ASTM A123/ISO 1461
手術: 油圧または電気モーター ナットとボルト: グレード 8.8/6.8/48
垂直偏差: <1/1000 応用: 移動体通信タワー
色: 顧客の要件に応じて 仕上げる: 耐食性のために塗られる粉
携帯性: 持ち運びが簡単な設計 耐荷重: 500kg
メンテナンス: モジュール式パーツによるメンテナンスの軽減 セクション: 3 ～ 6 つの伸縮セクション
重さ: 約1500kg 電源: バッテリーまたは外部電源

Versatile Telescopic Tower with Height Range from 15 to 30 Meters Suitable for Aerial Work and Industrial Installations



Telescopic Lattice Antenna Communication Tower is a revolutionary vertical structure designed for effortless height adjustment. Its nested sections expand or retract smoothly, making it ideal for aerial work, stage setups, or industrial installations.

Why Choose Our Telescopic Communication Tower?
Lightweight & Durable: Crafted from aerospace-grade steel, it's strong yet easy to transport.
Instant Height Control: Adjust from 3m to 10m in seconds-no tools needed!
Unmatched Stability: Anti-slip base and reinforced joints ensure safety at any elevation.
Versatile Applications: Perfect for construction, events, or maintenance tasks.


Need a comparison chart ? Just ask!

Product Description
Product Details
Height 15-30M
Wind Speed 40M/S
Main Material Steel Tube, Solid rod
Vertical Deviation <1/1000
Preservative Treatment Hot Dipped Galvanized and painting
What is the rising state of COW?
Rising State of COW (Telescopic Tower)‌.The rising state refers to the vertical extension phase, where the telescopic tower deploys its nested sections sequentially using hydraulic or electric actuators. Each section slides outward along precision-guided rails, maintaining structural alignment and load stability. This process is typically controlled via a centralized interface, allowing incremental height adjustment from 6 to 30 meters depending on design. The system incorporates load sensors and anti-tilt mechanisms to ensure safety during ascent. Common applications include mobile communication towers, temporary surveillance platforms, and high-intensity lighting systems deployed at construction or emergency sites.
Versatile Telescopic Tower with Height Range from 15 to 30 Meters Suitable for Aerial Work and Industrial Installations 0
What is the lying down process of COW?
Lying Down Process of COW (Telescopic Tower)‌.The lying down process — more accurately termed stowing to horizontal position — involves rotating the fully retracted or partially extended tower from vertical to horizontal orientation around a pivot point at its base. This is achieved through a hydraulic hinge mechanism that lowers the mast slowly and controllably, often with counterweights to balance torque. The process is critical for transportation, storm preparedness, or storage. Safety interlocks prevent movement unless all sections are fully retracted and locking pins are disengaged. Mobile lighting towers and radar masts commonly employ this feature to reduce wind load and enable trailer transport.
Versatile Telescopic Tower with Height Range from 15 to 30 Meters Suitable for Aerial Work and Industrial Installations 1
What is the retracting state of COW?
Retracting State of COW (Telescopic Tower)‌.The retracting state is the axial contraction of individual tower sections back into one another, reducing overall height while maintaining vertical alignment. Unlike the lying down process, retraction occurs with the tower still upright. Each section is pulled inward by winches or hydraulic cylinders, guided by telescoping sleeves and secured by mechanical locks at each stage. The sequence is reverse of extension: outermost section retracts first, followed by inner layers. This phase is typically performed before stowing to minimize structural stress and ensure compactness. Retraction is often automated and monitored via position encoders to prevent jamming or misalignment.
Versatile Telescopic Tower with Height Range from 15 to 30 Meters Suitable for Aerial Work and Industrial Installations 2
Certifications

Versatile Telescopic Tower with Height Range from 15 to 30 Meters Suitable for Aerial Work and Industrial Installations 3

Gular customers

Versatile Telescopic Tower with Height Range from 15 to 30 Meters Suitable for Aerial Work and Industrial Installations 4



Company Information

Versatile Telescopic Tower with Height Range from 15 to 30 Meters Suitable for Aerial Work and Industrial Installations 5

Our Services

Versatile Telescopic Tower with Height Range from 15 to 30 Meters Suitable for Aerial Work and Industrial Installations 6
